Forest Vegetation Type Monitoring in the Natural Forest Protection Project Area

doi:10.13466/j.cnki.lyzygl.2023.02.013

Abstract

Abstract:

Based on moderate resolution remote sensing images,forest vegetation type monitoring was performed to provide technical support for achievement monitoring of the natural forest protection project area and forest vegetation mapping.Based on Landsat8 OLI images in growing and non-growing seasons,random forest and time dimension correction methods were applied to forest vegetation type monitoring in Wangqing Forestry Bureau.Based on confusion matrix and recall ratio,factors leading to classification confusion were analyzed.The results showed that:1) Overall accuracy of forest vegetation type monitoring was 86.41%,and kappa coefficient was 0.82,illustrating a better classification effect.2) Among various forest vegetation types,deciduous broadleaved forest land had high classification accuracy,with producer's and user's accuracy of over 90%,respectively.Deciduous coniferous forest land had relatively high producer's accuracy of 86.96%.Evergreen coniferous forest land and coniferous and broadleaved mixed forest land had relatively low producer's and user's accuracies of average 75.19%.Classification confusion between evergreen coniferous forest,deciduous coniferous forest,deciduous broadleaved forest,and coniferous and broadleaved mixed forest frequently occurred as the result of mixed proportion,forest canopy closure and forest age.3) Forest coverage of Wangqing Forestry Bureau was 96.64%.The area proportion of deciduous broadleaved forest land was the largest,that of coniferous and broadleaved mixed forest land was the secondly largest,and that of deciduous coniferous forest land,evergreen coniferous forest land,shrubland and other forest land was small.The analysis showed that multitemporal and phenological information of moderate resolution remote sensing images was effective in obtaining forest vegetation types of the natural forest protection project area.

Key words: natural forest protection project area, forest vegetation type, multitemporal and phenological information, random forest, time dimension correction, Wangqing Forestry Bureau

CLC Number:

S771.8

WANG Xiaohui, ZHANG Huiru, PANG Yong, QIN Xianlin, LI Haikui, MENG Shili, YU Tao. Forest Vegetation Type Monitoring in the Natural Forest Protection Project Area[J]. FOREST RESOURCES WANAGEMENT, 2023, (2): 96-103.

Figures/Tables 7

Fig.1

Tab.1

Tab.2

Tab.3

Tab.4

Tab.5

Fig.2

References 19

[1]	黄建文, 胡庭兴, 张忠辉. 天然林资源保护工程监测技术[M]. 北京: 中国林业出版社, 2012.
[2]	刘洋, 肖中琪, 张怀清, 等. 新疆阿尔泰山天然林保护工程区2000—2016年林地类型变化分析[J]. 林业资源管理, 2019(1):70-77.
[3]	赖家明, 杨武年. 基于RS的川西天然林区近29年植被覆盖动态变化[J]. 国土资源遥感, 2018, 30(4):132-138.
[4]	李爱农, 边金虎, 张正健, 等. 山地遥感主要研究进展、发展机遇与挑战[J]. 遥感学报, 2016, 20(5):1199-1215.
[5]	Townshend J R G, Justice C O, Gurney C, et al. The impact of misregistration on change detection[J]. IEEE Transactions on Geoscience and Remote Sensing, 1992, 30(5):1054-1060. doi: 10.1109/36.175340
[6]	高若楠, 谢阳生, 雷相东, 等. 基于随机森林模型的天然林立地生产力预测研究[J]. 中南林业科技大学学报, 2019, 39(4):39-46.
[7]	钱钊晖, 王绍强, 陈敬华, 等. 表征亚热带常绿林光合作用季节变化特征的多种植被指数[J]. 生态学报, 2018, 38(16):5771-5781.
[8]	周蕾, 迟永刚, 刘啸添, 等. 日光诱导叶绿素荧光对亚热带常绿针叶林物候的追踪[J]. 生态学报, 2020, 40(12):4114-4125.
[9]	郭庆华, 关宏灿, 胡天宇, 等. 新一代1∶50万中国植被图绘制方法探讨[J]. 中国科学:生命科学, 2021, 51(3):229-241.
[10]	Immitzer M, Neuwirth M, Böck S, et al. Optimal input features for tree species classification in central Europe based on multi-temporal Sentinel-2 data[J]. Remote Sensing, 2019, 11(22):2599. doi: 10.3390/rs11222599
[11]	林丽群, 汪正祥, 雷耘, 等. 神农架川金丝猴栖息地优势乔木树种遥感识别及其分布特征[J]. 生态学报, 2017, 37(19):6534-6543.
[12]	Pang Yong, Li Zengyuan, Fan Shunxiang, et al. Fill invalid pixels of thematic map using composited image[C]// 2019 IEEE International Geoscience and Remote Sensing Symposium.Yokohama, Japan: IEEE, 2019:6748-6751.
[13]	TD/T 1055—2019,第三次全国国土调查技术规程[S].
[14]	GB/T 21010—2017,土地利用现状分类[S].
[15]	Meyer P, Itten K I, Kellenberger T, et al. Radiometric corrections of topographically induced effects on Landsat TM data in an alpine environment[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 1993, 48(4):17-28. doi: 10.1016/0924-2716(93)90028-L
[16]	Moreira E P, Valeriano M M. Application and evaluation of topographic correction methods to improve land cover mapping using object-based classification[J]. International Journal of Applied Earth Observation and Geoinformation, 2014, 32:208-217. doi: 10.1016/j.jag.2014.04.006
[17]	刘时城, 温仲明, 陶宇, 等. 不同地形校正方法对刺槐林遥感提取的影响[J]. 北京林业大学学报, 2017, 39(5):25-33.
[18]	Breiman L. Random forests[J]. Machine Learning, 2001, 45(1):5-32. doi: 10.1023/A:1010933404324
[19]	Cutler A, Cutler D R, Stevens J R. Random forests[M]//Zhang C,Ma Y Q.Ensemble machine learning:Methods and applications. New York,USA: Springer-Verlag, 2012:157-175.

分类类型	参考样本
分类类型	1	2	3	4	5	6	7	8	9	UA/%	CE/%
1	16	0	5	0	0	0	0	0	0	76.19	23.81
2	0	20	6	1	0	0	0	0	0	74.07	25.93
3	4	2	66	15	0	0	0	0	0	75.86	24.14
4	1	1	13	223	2	3	1	0	0	91.39	8.61
5	0	0	0	1	13	0	1	0	0	86.67	13.33
6	0	0	1	0	0	12	0	0	0	92.31	7.69
7	0	0	0	0	0	0	15	1	0	93.75	6.25
8	0	0	0	0	0	0	1	7	0	87.50	12.50
9	0	0	0	0	0	0	0	0	3	100.00	0.00
PA/%	76.19	86.96	72.53	92.92	86.67	80.00	83.33	87.50	100.00
OE/%	23.81	13.04	27.47	7.08	13.33	20.00	16.67	12.50	0.00
OA=0.8641 Kappa=0.82

参考样本	查全率	参考样本	查全率
常绿针叶纯林	81.82	常绿针叶混交林	60.00
落叶针叶纯林	86.36	落叶针叶混交林	100.00
落叶阔叶纯林	98.51	落叶阔叶混交林	91.86
针阔混交林	73.63

类型	面积/km²	比例/%
常绿针叶林地	43.08	1.38
落叶针叶林地	105.94	3.39
针阔混交林地	627.24	20.05
落叶阔叶林地	2246.88	71.82
灌木林地	0.88	0.03
其他林地	9.50	0.30
耕地	78.28	2.50
建设用地	11.65	0.37
水体	4.95	0.16
